UNI-T | Laser Levels | LM585R

✅ These laser levelers are equipped with red laser,which allows for fast, accurate layout of reference points and lines.

✅ They are ideal tools for stair laying,furniture installation, electrical and residential construction.

✅ Laser high-brightness display

✅ 360°emission angle

✅ Self-leveling

✅ Pendulum lock

✅ Laser diagonals

✅ Wireless remote control

Technical Specification

Laser tube: SHARP LD

Laser type: Red, high brightness

Laser lines: 8 lines

Laser wavelength: 635nm±10nm

Laser class: CLASS II

Horizontal accuracy: ≤±3mm/10m

Vertical accuracy: ≤±3mm/10m

Brightness adjustment: 3 scales adjustable

Laser linewidth: ≤5mm±1/10m (indoor lighting: 80~100lux)

Emission angle: Horizontal: 360°, vertical: 120°

Leveling range: ±(3±1)°

Minimum distance to wall/ground : 20mm

Battery life: ＞30h

Operating range: In the highest brightness, radius＞30m

Leveling modes: Magnetic damping, heavy hammer

Alarm modes: Buzzer + laser line flashes

Diagonal mode: √

Operating temperature: -10~50℃

Power supply: 3.7V 6000mAh

Standard accessories: Laser level, 6000mAh battery pack, Type-C cable, user manual, wall-mounted bracket + iron plate(not LM585R), remote control(not LM585R)，lifting table(only LM585R), tripod base(only LM585R), toolbox

Product size: 85×75×115mm
