• Power Input:1850 Watts

• Blade Speed: 3800 rpm

• Blade Diameter: 250 mm

• Blade Bore: 30 mm

• Bevel Capacity: -3 to 48

• Max. Ripping Capacity [right]: 610 mm

• Max. Ripping Capacity [left]: 315 mm

• Max. Depth of Cut at 90 : 77 mm

• Max. Depth of Cut at 45 : 57 mm

• Table Size: 630 x 570 mm

• Weight: 22 kg

• Depth: 742 mm

• Length: 577 mm

• Height: 425 mm

• Sound Power: 109 dB(A)

• Sound Power Uncertainty: 3 dB(A)

• Sound Pressure: 96 dB(A)

• Sound Pressure Uncertainty: 3 dB(A)

Specifications

• 22 kg unit weight and optimized footprint make this the most portable saw in its class

• Steel roll cage protects saw against job site drops and impacts

• Rack and pinion fence system; front and rear fence lock and large; clear scales combine to give an extremely accurate and easy to use saw

• Powerful 1850 Watt motor for high performance in all applications (1300 Watts 110 version for UK Only)

• Fence system provides 610 mm of rip capacity in a portable design for cutting large sheet materials to size

• Cast table top design ensures accuracy and precision

• Overload protection system ensures powerful performance in hard; wet or frozen woods

• Quick bevel lock with large scale for easy; accurate adjustments.
